Temperature Sensor Type P2208-T
- Standard Range: -50 … +50°C / 0 .. 100 °C
- Output: 4… 20 mA or 0… 10V
- Supply 12. .. 30 Vdc
- Accuracy: <± 0.4% of range
- Ambient temperature: -20…70°C
Option:
- EXi version on request
Specifications
Temperature Sensor Type P2208-T
APPLICATIONS:
• pneumatics / hydraulics
• Water
• food and beverage
• General Industrial Application
• Pharmaceutical Industry
The compact industrial screw-in transmitter P2208-T is designed for temperature measurement in liquids or gases in piping, air ducts or containers in mechanical engineering, plant engineering and apparatus engineering.
The active industrial screw-in transmitter P2208-T converts the temperature resistance of the sensor into a linear 0-10V voltage signal or a 4-20 mA current signal.
The sensor can be connected directly to a 1 / 4 inch screw-in tap hole.
The P2208-T is equipped with a G ¼” process connector.
Standard articles
Click on the article to automatically insert into the contact form below
To view our standard articles please visit from a desktop
Single contact
(1 contact point)
Avaliable contact types:
KN,KM,KE and KI
Contact Function : Break
1
Contact Function : Close
2
Contact Function : Shift
3
Contact Function Separate Circuits : Break
4
Contact Function Separate Circuits : Close
5
Double contact
(2 contact points)
Avaliable contact types:
KN,KM,KE and KI
Shift contact
(2 contact points switch function)
Avaliable contact types:
KN and KM
Double contact
(2 contact pointers seperate Circuits)
Avaliable contact types:
KN and KM
Triple contact
(3 contact pointers)
Avaliable contact types:
KN and KM
Triple contact
(3 contact pointers)
Avaliable contact types:
KN and KM
